| MODEL |
DWTH
-500H |
DWTH
-500M |
DWTH
-500L |
DWTH
-800H |
DWTH
-800M |
DWTH
-800L |
DWTH
-1000H |
DWTH
-1000M |
DWTH
-1000L |
| Temp. Range |
-20℃ ~
+100℃ |
-40℃ ~
+120℃ |
-70℃ ~
+150℃ |
-20℃ ~
+100℃ |
-40℃ ~
+120℃ |
-70℃ ~
+150℃ |
-20℃ ~
+100℃ |
-40℃ ~
+120℃ |
-70℃ ~
+150℃ |
| Humid. Range |
30~98%RH |
30~98%RH |
30~98%RH |
Internal
Dimension
(WxDxH m/m) |
500x500x600 |
800x600x800 |
1000x800x1000 |
Temperature
Humidity
Constancy |
±0.3℃ ±1.5%RH |
±0.3℃ ±1.5%RH |
±0.3℃ ±1.5%RH |
External
Material. |
Stainless Steel Sheet (SUS 304 CP / hairline finished) |
Internal
Insulator |
Stainless Steel Sheet (SUS 304 CP / hairline finished)
Hard polyurethan form (for the body), (Glass wool, for glass) |
| Heating Time |
+20℃ ~
+100℃
40min
|
+20℃ ~
+120℃
50min |
+20℃ ~
+150℃
40min |
-20℃ ~
+100℃
40min
|
-20℃ ~
+120℃
50min |
-20℃ ~
+150℃
60min |
+20℃ ~
+100℃
40min
|
+20℃ ~
+120℃
50min |
+20℃ ~
+150℃
60min |
| Cooling Time |
+20℃~
-20℃
within 40min |
+20℃~
-40℃
within 60min |
+20℃~
-70℃
within 90min |
+20℃~
-20℃
within 40min |
+20℃~
-40℃
within 60min |
+20℃~
-70℃
within 90min |
+20℃~
-20℃
within 40min |
+20℃~
-40℃
within 60min |
+20℃~
-70℃
within 40min |
Cooling
System |
Air - Cooled or water cooled or cascade System |
| Accessorries |
● Viewing Window ● In door Lamp ● Cable port(inside diameter - 50mm) |
| Safety Devices |
● Earth Leakage Breaker
● Short Circuit Breaker
● Humidity Heater Breaker
● Refrigerator Overload Relay
● High&Low Pressure Switch
● Protect Fuse
● Over Heat Breaker |
● Earth Leakage Breaker
● Over Heat Breaker
● Refrigerator Overload Relay
● Humidity Heater Breaker
● High&Low Pressure Switch
● Short Circuit Breaker |
● Earth Leakage Breaker
● Refrigerator Overload Relay
● High&Low Pressure Switch
● Over Heat Breaker
● Short Circuit Breaker
● Humidity Heater Breaker
● Protect Fuse |
