| MODEL |
DW-2000 |
DW-OB-2 |
DW-USER |
| Chamber volume |
2000x2000x2000
|
3000x2000x2000 |
USER 사양협의 |
| Control system |
PID auto-tuning/IDS-Control System |
|
|
사양에 따라 다름 user 요구사항 협의 |
| Temperature |
Working range |
|
Uniformity |
|
Stability | |
-60℃~150℃ (그외 온도사양도 주문제작 가능함) |
| ±2℃(Measure the sensor in 1/10 distance of the interior wall) |
| ±0.5℃ |
±0.5℃ |
|
| Humidity |
Working range |
|
Uniformity |
|
Stability | |
30 ~ 90％ RH |
| ±0.5％RH |
| ±2.5％RH |
|
|
45min (-40℃→100℃) |
| 60min (20℃→ -40℃) |
| Refrigeration |
System |
|
Refrigerant |
|
Capacity | |
단단냉동 및 이원냉동 방식 |
| R-22, R-404A(CFC-free),R-23 |
| 사양에 따라 다름 |
| Cooler |
Plate fin cooler |
| Sensor |
Temperature |
|
Humidity | |
Pt100Ω |
| Pt100 / 건,습구 Gauze, ( 전자식 습도센서 SH300 협의) |
| Material |
Interior |
|
Exterior |
|
Insulation |
|
Door | |
Stainless steel (SUS304) |
| Steel 1.2T with Epoxy Powder Coating |
| 세라믹울 |
| 세라믹울 |
| Interface |
RS485 (Option RS232협의) |
| Safety devices |
- Switch-off after alarm for Overheating, Water empty
-Current leak or over |
|
|
* |
* |
* |
| Electrical- Requirement |
220 VAC 50/60Hz 1Φ,3Φ( 380 VAC 50/60Hz 3Φ ) |
| LAMP |
IR LAMP 250W & 375W |
